Portable Hydraulic Hose Crimping Machine Brake Line Crimper Finn Power Crimper

Name: Portable Hydraulic Hose Crimping Machine Brake Line Crimper Finn Power Crimper
Brand: MENSION
Price: 1 USD

Wholesale Portable Hydraulic Hose Crimping Machine Brake Line Crimper Finn Power Crimper from china suppliers

Brand Name : MENSION

Model Number : MS-E150

Certification : CE RoHS

Place of Origin : CN

MOQ : 1 Set

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000 Sets Per Month

Delivery Time : 2 - 7 Working Days

Packaging Details : One Plywood For One Set

Price : Contact Us

Crimping Range : 14 - 127mm

Hose Size : 1/4 - 3inch

Die Sets : 15

Max. Opening : 35mm

Color : Blue

Crimping Force : 780T

Product Name : E150 Portable Hydraulic Hose Crimper

Application : Workshop

System Pressure : 31.5Mpa

Power : 3KW

Size : 650*550*650mm

Weight : 250Kg

Contact Now

FAMOUS PORTABLE HYDRAULIC HOSE CRIMPER MS-E150

DESCRIPTION

MS-E150 portable hydraulic hose crimping machinery is famous for its big hose crimping capacity with a compact structure. It is capable of crimping high pressure oil hoses, low pressure water ot air hoses, wire and cables, steel tubes etc.

MAIN FEATURES

1. Big crimping range fro 1/4 inch to 3 inch;

2. Forged steel making the cylinder, high stability;

3. Die sets are with high heat processing, high hardness.

TECHNICAL DATA

Model	MS-E150 Portable Hydraulic Hose Crimper
Crimping Range	14 - 127 (mm)
Crimping Force	780 (T)
Hose Size	1/4 - 3 (inch)
Max. Opening	35 (mm)
Die Sets	15
Die Set Type	150
System Pressure	31.5 (Mpa)
Accuracy	0.01 (mm)
Control	MS
Standard Voltage	220 (V) / 380 (V)
Motor Power	3 (KW)
Length	650 (mm)
Width	550 (mm)
Height	650 (mm)
Weight	250 (KG)

Portable Hydraulic Hose Crimping Machine Brake Line Crimper Finn Power Crimper

150 CRIMPER DIE SETS

Die No.	Crimping Range	Length
6*	6 - 8mm	55
8*	8 - 10mm	55
10*	10 - 12mm	55
12*	12 - 14mm	55
14	14 - 16mm	55
16	16 - 19mm	55
19	19 - 22mm	55
22	22 - 26mm	70
26	26 - 30mm	70
30	30 - 34mm	70
34	34 - 39mm	75
39	39 - 45mm	75
45	45 - 51mm	90
51	51 - 57mm	90
57	57 - 63mm	100
63	63 - 69mm	110
69	69 - 74mm	110
74	74 - 78mm	110
78	78 - 87mm	110

NOTE

1) Customized die sets are available with different size or shape;

2) Special voltage such as 110V, 208V, 240V, 415V are availbale;

3) Foot pedal is available to make the hands free;

4) * for non standard die sets.
